PVL-144W flexible solar panel for BIPV
original price: 3,40 USD
Frank Lee
Contact person
Basic Information
| Place of Origin | Fujian China (Mainland) |
|---|---|
| Brand Name | UISOLAR |
| Model Number | PVL-144 |
| Size | 5486*394*4mm(216"*15.5"*0.2") |
| Number of Cells | 22 |
| Max. Power | 144W |
| Material | Amorphous Silicon |
flexible solar panel Rated Power (Pmax): 144Wp; Qualifications and Safety: UL1703, IEC61646/61730, TUV. Warranty: 5 Years Limited product warranty.92% at 10 years, 84% at 20 years, 80% at 25 years (of the minimum power)specifications:1) Peak power (Wp): 144W2) Module efficiency: 8.69%3) Max. Power voltage (Vmp): 33.0V4) Max. Power current (Imp): 4.36A5) Open circuit voltage (Voc): 46.2V6) Short circuit current (Isc): 5.3A7) Dimensions: 5486*394*4mm(216"*15.5"*0.2")8) Weight: 7.7KG (17.0 lbs) 9)22 triple junction amorphous silicon solar cells 356*239mm10) Warranty:92% at 10 years, 84% at 20 years, 80% at 25 years (of the minimum power)
Delivery terms and packaging
Packaging Detail: Corrugated Box, Plywood Box and Wooden Box are available. Delivery Detail: 7 days for samples; others as per order quantity.
Port: Xiamen
